Aluminum Industrial Profile

Aluminum Industrial Profile

The advantages of aluminum alloy are lightweight, excellent electrical and thermal conductivity, high corrosion resistance and ductility.

Aluminum alloy is soft and usually alloyed with copper, zinc, magnesium, silicon, manganese and lithium to increase strength. When aluminum alloy is exposed to air, an anti-oxidant coating will be formed instantly to protect products. Aluminum alloy is one of the lightest metals. The application of products ranges from precision technology to daily commodities.

Mechanical Properties

  • Tensile Strength, Ultimate
  • 120 ~ 290 Mpa
  • Tensile Strength, Yield
  • 60 ~ 240 Mpa
  • Hardness, Brinell
  • 40 ~ 88

Product Specification and Size :

Standard Specification:  GB/T 6892, ASTM B221, EN 755

Alloy and Temper
Alloy Temper
6xxx: 6005, 6060, 6061, 6063, 6463 T4, T5, T6

Alloy Designation (For Reference)

Comparison of Alloy Designations for Aluminum Products

Alloy Series Chinese Standard American Standard European Standard
6xxx Series 6005 6005 -
6060 6060 EN AW-6060
6061 6061 EN AW-6061
6063 6063 EN AW-6063
6463 6463 EN AW-6463

Temper Designation (For Reference)

Temper Definition
T4 Solution heat-treated and naturally aged
T5 Cooled from an elevated temperature shaping process and then artificially aged
T6 Solution heat-treated and then artificially aged

Available Size Range

Dimension Range
Circumscribing Circle < 400mm
Length 1,000~6,000mm

- Production Process: Extruded
- Form: Usually special shapes, or as per confirmed drawings
- Surface Finish: Mill Finish, Anodized

Application

Aluminum alloy industrial profiles are high strength along with high corrosion resistance, making the best choice for infrastructure, construction, transportation and light railway track projects. 6000 series aluminum alloy industrial profiles are known for their high flexibility.

Type Application
Construction Aluminum windows/ doors, aluminum double glass sliding windows, colored windows, high rise windows, curtain wall, aluminum railing, aluminum balustrades
Transportation Bumper, door beam, space frame, light railway track

Chemical Composition (For Reference)

Chemical Composition conforms to Chinese, American and European standard specification

Alloy Si Fe Cu Mn Mg Cr Zn Ti Others:
Each		 Others:
Total		 Al: Min.
5052 0.25 0.40 0.10 0.10 2.20~2.8 0.15~0.35 0.10 - 0.05 0.15 remainder
6060 0.30~0.60 0.10~0.3 0.10 0.10 0.35~0.60 0.05 0.15 0.10 0.05 0.15 remainder
6061 0.40~0.80 0.70 0.15~0.40 0.15 0.80~1.20 0.04~0.35 0.25 0.15 0.05 0.15 remainder
6063 0.20~0.60 0.35 0.10 0.10 0.45~0.90 0.10 0.10 0.10 0.05 0.15 remainder
6463 0.20~0.60 0.15 0.20 0.05 0.45~0.90 - 0.05 - 0.05 0.15 remainder
