Stainless Steel Sheet

Stainless Steel Sheet

The properties of stainless steel are corrosion resistance, high ductility, attractive appearance and low maintenance.

Stainless steel contains chromium which provides the properties of corrosion resistance at high temperatures. Stainless steel can withstand corrosive or chemical environments due to its smooth surface. Stainless steel products are safe for long-term use with excellent resistance of corrosion fatigue.

Chemical Composition

Steel Grade
  • 304 Steel Grade C%
  • 0.08%
  • 304 Steel Grade Cr%
  • 18.0~20.0%
  • 304 Steel Grade Ni%
  • 8.0~10.5%
  • 316L Steel Grade C%
  • 0.03%
  • 316L Steel Grade Cr%
  • 16.0-18.0%
  • 316L Steel Grade Ni%
  • 12.0-15.0%

Product Specification and Size :

Product Specification and Steel Grade (For Reference)

  ASTM JIS AISI EN Mill's Standard
Grade S30100
S30400
S30403
S31008
S31603
S32100
S41008
S43000
S43932
S44400
S44500		 SUS301
SUS304
SUS304L
SUS310S
-
SUS321
SUS410S
SUS430
-
SUS444
SUS430J1L		 301
304
304L
310S
316L
321
410S
430
-
444
-		 1.4310
1.4301
1.4307
1.4845
1.4404
1.4541
-
1.4016
1.4510
1.4521
-		 201
202
204Cu3

Available Size

Width: 914~1524 mm
Thickness: 0.1~3.0 mm
Length: 300~6000 mm
Available Steel Grade: 201, 202, 204 Cu3, 301, 304, 304L, 310S, 316L, 321, 409L, 410S, 420J2, 430, 439, 441, 444, 445
Surface Finish: No.1, 2B, BA, No.3, No.4, No.5, No.8, HL, Etching, SB, Ti-coating

Application

Stainless sheet is used for industrial sectors and components for processing equipment for foodservice, medical device, chemical, petrochemical and power transmission industries.

stainless steel kitchen equipment
stainless steel kitchen equipment

Tolerance of Width

Tolerance of Width
W < 100 mm 100 mm ≦ W < 1000 mm 1000 mm ≦ W < 1600 mm
± 0.10 mm ± 0.25 mm ± 0.30 mm

Chemical Composition & Mechanical Property

Chemical Composition (For Reference)

ASTM Specification
Spec.
ASTM
A240
Steel Grade Ni% Max. Cr% Max. C% Max. Si% Max. Mn% Max. P% Max. S% Max. Mo% Max. Ti% Max. Other
S30100 6.0~8.0 16.0~18.0 0.15 1 2 0.045 0.03 - - N: 0.1 Max.
S30400 8.0~10.5 17.5~19.5 0.07 0.75 2 0.045 0.03 - - N: 0.1 Max.
S30403 8.0~12.0 17.5~19.5 0.03 0.75 2 0.045 0.03 - - N: 0.1 Max.
S31008 19.0~22.0 24.0~26.0 0.08 1.5 2 0.045 0.03 - - -
S31603 10.0~14.0 16.0~18.0 0.03 0.75 2 0.045 0.03 2.0~3.0 - N: 0.1 Max.
S32100 9.0~12.0 17.0~19.0 0.08 0.75 2 0.045 0.03 - 5(C+N)~0.70 N: 0.1 Max.
S41000 0.75 11.5~13.5 0.08~0.15 1 1 0.04 0.03 - - -
S43000 0.75 16.0~18.0 0.12 1 1 0.04 0.03 - - -
S43932 0.5 17.0~19.0 0.03 1 1 0.04 0.03 - - N: 0.03 Max.
Al: 0.15 Max.
Nb+Ti = [ 0.20 + 4 ( C + N ) ] ~ 0.75


Mechanical Property (For Reference)

ASTM Specification
Spec.
ASTM
A240
Steel Grade N/mm 2 MIN.
Tensile Stress		 N/mm 2 MIN.
Proof Stress		 % MIN.
Elongation		 HRB MAX.
Hardness		 HBW MAX.
Hardness		 Bendability:
Bending Angle		 Bendability:
Inside Radius
S30100 515 205 40 95 217 No Require -
S30400 515 205 40 92 201 No Require -
S30403 485 170 40 92 201 No Require -
S31008 515 205 40 95 217 No Require -
S31603 485 170 40 95 217 No Require -
S32100 515 205 40 95 217 No Require -
S41000 450 205 20 96 217 180° -
S43000 450 205 22A 89 183 180° -
