Aluminum Plate
Yieh Corp.’s Aluminum Plates are engineered to provide superior performance in a wide range of industries, including construction, aerospace, transportation, marine, and manufacturing. Aluminum Plates are produced according to stringent ISO standard processes and are available in various grades, tempers, thicknesses, and finishes to meet your specific design and functional requirements.
Available Size
| Alloy | Temper | Thickness (mm) | Width (mm) | Length (mm) |
| 3004, 3005, 3104, 3105 | F, O, H12, H14, H16, H18, H19, H22, H24, H26, H28, H111, H112, H114 | 0.5 - 6.0 | 1000 - 2200 | 2000 - 10000 |
| 5005, 5052, 5059, 5083, 5086, 5182, 5252, 5454, 5754 | O, H12, H14, H16, H18, H19, H22, H24, H26, H28, H32, H34, H36, H38, H111, H112, H114, H116, H321 | 6.0 - 120 | 1000 - 2200 | 2000 - 10000 |
| 6005, 6061, 6063, 6082 | O, T4, T6, T651 | 6.0 - 120 | 1000 - 2200 | 2000 - 10000 |
Aluminum Surface Finishes & Protection
| Surface Finishes | Description | Features | Protection |
| Mill Finish | The natural finish of aluminum after rolling, without additional processing. | Non-uniform reflectivity, and a slightly rough surface with a matte or dull metallic sheen. | Paper interleaved, PE/PVC filming (if specified) |
| Anodizing | An electrochemical process that thickens the natural oxide layer on the aluminum surface. | Enhances corrosion resistance, hardness, and allows for coloring. | |
| Powder Coating | A dry finishing process where a powder is electrostatically applied and cured under heat. | Durable, colorful, and resistant to chipping, scratching, and fading. | |
| Brushed Finish | The surface is mechanically polished to create a uniform satin texture. | A linear texture and reduced reflectivity for a decorative feel. | |
| Mirror Finish (Polishing) | The aluminum sheet is polished to a highly reflective, mirror-like surface. | Smooth, glossy, and highly reflective. | |
| Embossing | The aluminum sheet is passed through rollers that emboss a raised or patterned texture on the surface. | Adds visual appeal and increases strength and rigidity. | |
| Sandblasted Finish | The surface is roughened using high-speed abrasive blasting. | Decorative surfaces, pre-treatment for painting |
Packaging of Aluminum Plate
| Surface Protection | Waterproof Sealing | Securing and Palletizing |
| The surface of the Aluminum Plate is covered with a protective layer of polyethylene (PE) film, laser film, or oil to prevent oxidation and dirt accumulation. | Aluminum Plates are securely wrapped in waterproof materials, including plastic film, shrink wrap, or waterproof kraft paper. Desiccants may be placed inside the packaging to prevent moisture buildup. | The wrapped Aluminum Plates are securely strapped to wooden or metal pallets using durable steel or plastic bands, ensuring stability and safety in transit. |
Specification of Aluminum Plate (For Reference)
Comparison of Alloy Designations for Aluminum Products
| Alloy Series | Chinese Standard | American Standard | European Standard |
| 3000 Series | 3004 | 3004 | EN AW-3004 |
| 3005 | 3005 | EN AW-3005 | |
| - | 3104 | EN AW-3104 | |
| 3105 | 3105 | EN AW-3105 | |
| 5000 Series | 5005 | 5005 | EN AW-5005 |
| 5052 | 5052 | EN AW-5052 | |
| 5083 | 5083 | EN AW-5083 | |
| 5086 | 5086 | EN AW-5086 | |
| 5182 | 5182 | EN AW-5182 | |
| 5252 | 5252 | EN AW-5252 | |
| 5454 | 5454 | EN AW-5454 | |
| 5754 | 5754 | EN AW-5754 | |
| 6000 Series | 6005 | 6005 | EN AW-6005 |
| 6061 | 6061 | EN AW-6061 | |
| 6063 | 6063 | EN AW-6063 | |
| 6082 | 6082 | EN AW-6082 |
Temper Designation (For Reference)
| Temper | Definition |
| O | Annealed |
| H12 H14 H16 H18 H19 |
Strain-hardened, 1/4 hard Strain-hardened, 1/2 hard Strain-hardened, 3/4 hard Strain-hardened, full hard Strain-hardened, extra hard |
| H22 H24 H26 H28 |
Strain-hardened and partially annealed, 1/4 hard Strain-hardened and partially annealed, 1/2 hard Strain-hardened and partially annealed, 3/4 hard Strain-hardened and partially annealed, full hard |
| H32 H34 H36 H38 |
Strain-hardened and stabilized, 1/4 hard Strain-hardened and stabilized, 1/2 hard Strain-hardened and stabilized, 3/4 hard Strain-hardened and stabilized, full hard |
| H111 H112 H114 H116 |
Annealed and slightly strain-hardened (less than H11) during subsequent operations such as stretching or levelling Slightly strain-hardened from working at an elevated temperature from a limited amount of cold work (mechanical property limits specified) Applies to embossed or patterned sheet or strip, fabricated from the corresponding Hxx temper Applies to aluminum-magnesium alloys with a magnesium content of 4% or more and for which mechanical property limits and exfoliation corrosion resistance are specified |
| H321 | Strain hardened less than required for a controlled H32 temper |
| T4 | Solution heat-treated and naturally aged |
| T6 | Solution heat-treated and then artificially aged |
| T651 | Solution heat-treated, stress-relieved by controlled stretching, and then artificially aged |
Chemical Composition (For Reference)
Chemical Composition conforms to Chinese, American and European standard specification
| Alloy | Si | Fe | Cu | Mn | Mg | Cr | Zn | Ti | Others: Each |
Others: Total |
Al: Min. |
| 3004 | 0.30 | 0.70 | 0.25 | 1.00-1.50 | 0.80-1.30 | - | 0.25 | - | 0.05 | 0.15 | remainder |
| 3005 | 0.60 | 0.70 | 0.30 | 1.00-1.50 | 0.20-0.60 | 0.10 | 0.25 | 0.10 | 0.05 | 0.15 | remainder |
| 3104 | 0.60 | 0.80 | 0.05-0.25 | 0.30-0.80 | 0.20-0.80 | - | 0.25 | 0.10 | 0.05 | 0.15 | remainder |
| 3105 | 0.60 | 0.70 | 0.30 | 0.30-0.80 | 0.20-0.80 | 0.20 | 0.40 | 0.10 | 0.05 | 0.15 | remainder |
| 5005 | 0.30 | 0.70 | 0.20 | 0.20 | 0.50-1.10 | 0.10 | 0.25 | - | 0.05 | 0.15 | remainder |
| 5052 | 0.25 | 0.40 | 0.10 | 0.10 | 2.20-2.80 | 0.15-0.35 | 0.10 | - | 0.05 | 0.15 | remainder |
| 5083 | 0.40 | 0.40 | 0.10 | 0.4-1.0 | 4.00-4.90 | 0.05-0.25 | 0.25 | 0.15 | 0.05 | 0.15 | remainder |
| 5086 | 0.40 | 0.50 | 0.10 | 0.2-0.7 | 3.50-4.50 | 0.05-0.25 | 0.25 | 0.15 | 0.05 | 0.15 | remainder |
| 5182 | 0.20 | 0.35 | 0.15 | 0.2-0.5 | 4.00-5.00 | 0.10 | 0.25 | 0.10 | 0.05 | 0.15 | remainder |
| 5454 | 0.25 | 0.40 | 0.10 | 0.50 | 2.40-3.00 | 0.05-0.20 | 0.25 | 0.20 | 0.05 | 0.15 | remainder |
| 5754 | 0.40 | 0.40 | 0.10 | 0.50 | 2.60-3.60 | 0.30 | 0.20 | 0.15 | 0.05 | 0.15 | remainder |
| 6005 | 0.6-0.90 | 0.35 | 0.10 | 0.10 | 0.40-0.60 | 0.10 | 0.10 | 0.10 | 0.05 | 0.15 | remainder |
| 6061 | 0.40-0.80 | 0.70 | 0.15-0.40 | 0.15 | 0.80-1.20 | 0.04-0.35 | 0.25 | 0.15 | 0.05 | 0.15 | remainder |
| 6063 | 0.20-0.60 | 0.35 | 0.10 | 0.10 | 0.45-0.90 | 0.10 | 0.10 | 0.10 | 0.05 | 0.15 | remainder |
| 6082 | 0.70-1.30 | 0.50 | 0.10 | 0.40-1.00 | 0.60-1.20 | 0.25 | 0.20 | 0.10 | 0.05 | 0.15 | remainder |
Application of Aluminum
Home Appliance Panels
Aluminum Plates provide a sleek, modern appearance while offering scratch resistance and corrosion protection. They are commonly used in appliances such as refrigerators, ovens, washing machines, and air conditioners.
Marine Parts
Aluminum Plates are the preferred material for hulls, decks, and structural components due to their excellent resistance to saltwater corrosion, high strength, and superior weldability.
Transportation Equipment
The lightweight properties of Aluminum Plates contribute to improved fuel efficiency in trailers, commercial vehicles, buses, and rail systems, while also meeting the complex design and structural requirements of modern transportation.
Aircraft Welding Parts
Aluminum Plates are essential in aerospace manufacturing for aircraft skin, structural supports, and welding assemblies due to their excellent fatigue resistance and lightweight properties.
Architectural Decorations
Aluminum Plates are widely used in curtain walls, ceiling panels, wall cladding, and decorative facades due to their modern appearance, excellent formability, and resistance to weathering.
Chemical Storage
Aluminum Plates are resistant to chemical corrosion in extreme environments, ensuring the safe and long-term use of chemical tanks, piping, and container systems.
Home Appliance Panels
Aluminum Plates provide a sleek, modern appearance while offering scratch resistance and corrosion protection. They are commonly used in appliances such as refrigerators, ovens, washing machines, and air conditioners.
Marine Parts
Aluminum Plates are the preferred material for hulls, decks, and structural components due to their excellent resistance to saltwater corrosion, high strength, and superior weldability.
Transportation Equipment
The lightweight properties of Aluminum Plates contribute to improved fuel efficiency in trailers, commercial vehicles, buses, and rail systems, while also meeting the complex design and structural requirements of modern transportation.
Aircraft Welding Parts
Aluminum Plates are essential in aerospace manufacturing for aircraft skin, structural supports, and welding assemblies due to their excellent fatigue resistance and lightweight properties.
Architectural Decorations
Aluminum Plates are widely used in curtain walls, ceiling panels, wall cladding, and decorative facades due to their modern appearance, excellent formability, and resistance to weathering.
Chemical Storage
Aluminum Plates are resistant to chemical corrosion in extreme environments, ensuring the safe and long-term use of chemical tanks, piping, and container systems.
