Stainless Steel Cold Rolled Coil
Elevate your projects with certified, high-performance Stainless Steel Cold Rolled Coils, designed to deliver excellence in every application. Stainless Steel Cold Rolled Coils are precision-engineered products known for their exceptional strength, durability, and sleek finish. Manufactured through a cold rolling process, they offer consistent thickness, superior surface quality, and enhanced mechanical properties. Available in various grades, such as 304, 316L, and 430, Yieh's Stainless Steel Cold Rolled Coils cater to a wide range of industrial and commercial applications.
Corrosion-Resistance
Chromium content of 16.0-18.0% can protect steel from rust and corrosion.
Heat Resistance
Nickel enhances the heat resistance of stainless steel, enabling it to maintain toughness at elevated temperatures.
Strength and Durability
Small amounts of carbon improve the strength and hardness of stainless steel.
| Width | Thickness | Inner Diameter | Available Steel Grade |
| 610 - 2000 mm | 0.3 - 6.0 mm | 610 or 508 +0/-5 mm | 201, 202, 204 Cu3, 301, 304, 304L, 310S, 316L, 321, 409L, 410S, 420J2, 430, 439, 441, 444, 445 |
|
Width Thickness |
W < 1250 | 1250 ≤ W < 1600 |
| 0.30 ≤ T < 0.60 | ± 0.05 | ± 0.08 |
| 0.60 ≤ T < 0.80 | ± 0.07 | ± 0.09 |
| 0.80 ≤ T < 1.00 | ± 0.09 | ± 0.10 |
| 1.00 ≤ T < 1.25 | ± 0.10 | ± 0.12 |
| 1.25 ≤ T < 1.60 | ± 0.12 | ± 0.15 |
| 1.60 ≤ T < 2.00 | ± 0.15 | ± 0.17 |
| 2.00 ≤ T < 2.50 | ± 0.17 | ± 0.20 |
| 2.50 ≤ T < 3.15 | ± 0.22 | ± 0.25 |
| 3.15 ≤ T < 4.00 | ± 0.25 | ± 0.30 |
| 4.00 ≤ T < 5.00 | ± 0.35 | ± 0.40 |
| 5.00 ≤ T < 6.00 | ± 0.40 | ± 0.45 |
|
Classification by Edge |
800 ≤ W < 1000 | 1000 ≤ W < 1524 | 1524 ≤ W |
| Mill Edge | 0/+25 | 0/+50 | 0/+50 |
| Cut Edge | 0/+5 | 0/+5 | 0/+10 |
| Surface Finish | Definition | Application | |
 2B
|
Those finished, after cold rolling, by heat treatment, pickling, or other equivalent treatment, and lastly by cold rolling to give an appropriate luster. | Medical equipment, food industry, construction material, kitchen utensils | |
 BA
|
Those processed with bright heat treatment after cold rolling. | Kitchen utensils, electric equipment, building construction | |
 No.4
|
Those finished by polishing with No.150 to No.180 abrasives specified in JIS R6001. | Kitchen utensils, building construction, medical equipment | |
 Etching
|
The etched technique is utilized to create unique patterns or designs on metal surfaces. The depth of the grooved surface can be made by machine depending on the different etching. | Building construction panel, elevator, interior decoration | |
 HL
|
Those finished by polishing so as to give continuous polishing streaks by using abrasive of suitable grain size. | Building construction | |
 Ti-Coating
|
The Ti-coating technique is a booming technology transferring from aerospace technology and applies the principle of ion exchange to adhere titanium ions onto the material surface under vacuum and high-temperature conditions. | Building decoration, artistry | |
Yieh's Stainless Steel Cold Rolled Coils comply with several international standards, including ASTM, JIS, and EN. We primarily provide various grades, such as 200 series, 300 series, and 400 series. All our products are internationally certified to ensure the safety and reliability of your projects.
|
Standard
UNS
|
JIS | AISI / ASTM | DIN | Mill’s Standard | |
|
Grade
S30400
S30403 S31008 S31603 S32100 S41000 S43000 S43035 S44400 |
SUS301 SUS304 SUS304L SUS310S SUS316L SUS321 SUS410 SUS420J1 SUS430 SUS430LX SUS444 |
301 304 304L 310S 316L 321 410 420 430 439 444 |
1.4310 1.4301 1.4306 1.4845 1.4404 1.4541 1.4006 1.4021 1.4016 1.4510 1.4521 |
201 202 204Cu3 |
|
Other specifications are also available up to request.
| Steel Grade | Ni% Max. | Cr% Max. | C% Max. | Si% Max. | Mn% Max. | P% Max. | S% Max. | Mo% Max. | Ti% Max. | Other |
| SUS304 | 8.0~10.5 | 18.0~20.0 | 0.08 | 1 | 2 | 0.045 | 0.03 | - | - | - |
| SUS304L | 9.0~13.0 | 18.0~20.0 | 0.03 | 1 | 2 | 0.045 | 0.03 | - | - | - |
| SUS316L | 12.0~15.0 | 16.0~18.0 | 0.03 | 1 | 2 | 0.045 | 0.03 | 2.0~3.0 | - | - |
| SUS430 | 0.60 | 16.0~18.0 | 0.12 | 0.75 | 1 | 0.04 | 0.03 | - | - | - |
| Steel Grade | Ni% Max. | Cr% Max. | C% Max. | Si% Max. | Mn% Max. | P% Max. | S% Max. | Mo% Max. | Ti% Max. | Other |
| S30400 | 8.0~10.5 | 17.5~19.5 | 0.07 | 0.75 | 2 | 0.045 | 0.03 | - | - | N: 0.1 Max. |
| S30403 | 8.0~12.0 | 17.5~19.5 | 0.03 | 0.75 | 2 | 0.045 | 0.03 | - | - | N: 0.1 Max. |
| S31603 | 10.0~14.0 | 16.0~18.0 | 0.03 | 0.75 | 2 | 0.045 | 0.03 | 2.0~3.0 | - | N: 0.1 Max. |
| S43000 | 0.75 | 16.0~18.0 | 0.12 | 1 | 1 | 0.04 | 0.03 | - | - | - |
| Steel Grade | N/mm 2 MIN. Tensile Stress |
N/mm 2 MIN. Proof Stress |
% MIN. Elongation |
HRB MAX. Hardness |
Bendability: Bending Angle |
Bendability: Inside Radius |
| SUS304 | 520 | 205 | 40 | 90 | No Require | - |
| SUS304L | 480 | 175 | 40 | 90 | No Require | - |
| SUS316L | 480 | 175 | 40 | 90 | No Require | - |
| SUS430 | 420 | 205 | 22 | 88 | 180° | 1.0 time the thickness |
| Steel Grade | N/mm 2 MIN. Tensile Stress |
N/mm 2 MIN. Proof Stress |
% MIN. Elongation |
HBW MAX. Hardness |
HRB MAX. Hardness |
Bendability: Bending Angle |
Bendability: Inside Radius |
| S30400 | 515 | 205 | 40 | 92 | 201 | No Require | - |
| S30403 | 485 | 170 | 40 | 92 | 201 | No Require | - |
| S31603 | 485 | 170 | 40 | 95 | 217 | No Require | - |
| S43000 | 450 | 205 | 22 | 89 | 183 | 180° | - |
Stainless Steel Cold Rolled Coils offer heat resistance and high-strength properties, making them ideal for aerospace engineering applications. They are utilized in aircraft frames, engines, and high-performance parts that demand reliability under extreme conditions.
Stainless Steel Cold Rolled Coils are the primary material used in the production of household appliances, including refrigerators, ovens, dishwashers, and washing machines. The aesthetically pleasing polished surface and hygienic properties of stainless steel cold-rolled coils make them an ideal choice for these applications.
Stainless Steel Cold Rolled Coils are essential for manufacturing components such as automotive exhaust systems and fuel tanks. Their high strength enhances vehicle performance, while corrosion resistance ensures a longer service life under harsh road and environmental conditions.
Stainless Steel Cold Rolled Coils are widely utilized in the construction industry for cladding, roofing, and structural components. Their excellent corrosion resistance ensures durability in extreme weather conditions. The No. 4 or HL surface is often regarded as an ideal material for decorative elements such as building exterior walls, railings, and interior panels.
