JIS G4304 Thickness Tolerance (mm)

Thickness \ Width

 W < 1000 1000 ≤ W < 1250 1250 ≤ W < 1600
2.00 ≤ T < 2.50 ± 0.25 ± 0.30 -
2.50 ≤ T < 3.15 ± 0.30 ± 0.35 ± 0.40
3.15 ≤ T < 4.00 ± 0.35 ± 0.40 ± 0.45
4.00 ≤ T < 5.00 ± 0.40 ± 0.45 ± 0.50
5.00 ≤ T < 6.00 ± 0.50 ± 0.55 ± 0.60
6.00 ≤ T < 8.00 ± 0.60 ± 0.65 ± 0.65
8.00 ≤ T < 10.00 ± 0.65 ± 0.65 ± 0.65



JIS G4304 Thickness Tolerance (mm)

Classification by Edge

 Thickness \ Width 800 ≤ W < 1000 1000 ≤ W
Mill Edge - 0/+25 0/+50
Cut Edge T < 6 0/+10 0/+10
T ≥ 6 0/+10 0/+15 0/+15



Specification of Stainless Steel

Yieh's Stainless Steel Hot Rolled Coils comply with several international standards, including ASTM, JIS, and EN. We primarily provide various grades, such as 200 series, 300 series, and 400 series. All our products are internationally certified to ensure the safety and reliability of your projects.

Chemical Composition of JIS Specification

Japanese Industrial Standards (JIS) specifies the standards used for industrial activities in Japan.

Chemical Composition of ASTM Specification

ASTM specifications for steel are a set of guidelines that classify, evaluate, and specify the properties of steel.

Mechanical Property of JIS Specification

Japanese Industrial Standards (JIS) specifies the standards used for industrial activities in Japan.

Mechanical Property of ASTM specifications

ASTM specifications for steel are a set of guidelines that classify, evaluate, and specify the properties of steel.
